I’m working with grayscale images and wondering if I can use skimage’s Region Adjacency Graph functionality for merging regions based on pixel intensity values rather than color information. Most examples I see focus on color-based merging, but my use case involves single-channel grayscale data. Is it possible to apply RAG merging techniques to grayscale images where regions would be merged according to their intensity similarities? I need to know if the library supports this type of processing or if there are specific modifications required for grayscale input.
Yeah, RAG works great with grayscale images. The main difference is you’re dealing with single-channel intensity instead of RGB values. I used this for document analysis and rag_mean_color still works fine - it just computes means for whatever channels you’ve got. For grayscale merging, I usually go with cut_threshold or cut_normalized_cut since they compare intensity stats between neighboring regions. Getting the threshold right is critical though - set it too low and you’ll over-segment everything, too high and you’ll lose important boundaries. What worked best for me was running gaussian filtering first to kill the noise, then building the RAG and applying merge_mean_color in loops until I hit the region count I wanted.
Here’s what nobody’s mentioned - manual RAG tuning is a time sink. You’ll waste hours tweaking thresholds and parameters for each grayscale dataset.
I automate everything now. My workflows handle preprocessing, initial segmentation, RAG building, parameter testing, and validation against ground truth automatically.
On a microscopy project, I built a system that processes grayscale batches, tries multiple threshold values, compares results, and picks the best settings based on region count and boundary quality. What took hours of manual tweaking now runs while I’m doing other stuff.
The magic happens when you chain everything together. One pipeline handles gaussian filtering, watershed segmentation, RAG building, and merging. It even adjusts parameters based on noise levels and contrast.
You don’t need complex code for this. Just build workflows that take your grayscale images from input to final merged regions.
definitely doable! i’ve done rag on grayscale thermal images plenty of times without problems. the main thing is getting your initial segmentation right - if you’re running watershed or something similar before building the rag, make sure it’s tuned for grayscale. also, future.graph.cut_threshold works really well for intensity-based merging since it looks at contrast between regions instead of just averaging them.
Absolutely works with grayscale - I’ve been doing this for years on satellite imagery and manufacturing defect detection. RAG treats intensity as just another feature vector, so RGB or single channel doesn’t matter to the algorithm.
I’d experiment with different similarity functions beyond mean intensity. Sometimes variance or texture measures work better depending on your data. For manufacturing inspection, I combine mean intensity with standard deviation to catch subtle texture differences that pure intensity averaging misses.
One thing others didn’t mention - if your grayscale data has specific intensity ranges that matter (like medical images with Hounsfield units), normalize or window your data before building the RAG. This stops the algorithm from getting confused by intensity outliers.
Here’s a solid example walkthrough that covers exactly what you’re asking about:
The rag_boundary function is also worth trying if your regions have clear edges. Sometimes it performs better than mean color approaches for grayscale data with distinct boundaries.
Yes, skimage’s RAG is effective with grayscale images. I’ve utilized it extensively for medical image segmentation, merging regions based on intensity. The RAG framework treats grayscale values like any feature, allowing for merging based on mean intensity or other metrics. When creating the RAG from your grayscale data, it calculates and retains intensity statistics as node attributes. Merging then relies on these attributes instead of color channels. I recommend using merge_hierarchical with a custom weight function to compare mean intensities of neighboring regions. The threshold defines the similarity required for merging. A tip from experience: lightly smoothing your grayscale image beforehand results in cleaner region boundaries post-merging.
